400V,235H3
Product Brochure:DOWNLOAD
Brief introduction
Super Fast Recovery Diode module,MUR40040,produced by TECHSEM .
Features：
Typical Applicatqions：
|
SYMBOL |
CHARACTERISTIC |
TEST CONDITIONS |
Tj(℃) |
VALUE |
UNIT |
||
Min |
Type |
Max |
|||||
|
IF(AV) |
Mean forward current |
Per Device (Tc=100℃ |
150 |
|
|
400 |
A |
Per Leg (Tc=100℃ |
|
|
200 |
A |
|||
IF(RMS) |
Mean forward current |
|
150 |
|
|
628 |
A |
VRRM |
Repetitive peak voltage |
tp=10ms VRSM= VRRM |
150 |
|
|
400 |
V |
|
IRRM |
Repetitive peak current |
@VRRM |
25 |
|
|
100 |
μA |
150 |
|
|
1000 |
μA |
|||
IFSM |
Surge forward current |
Per Leg , 10ms haif sine wave |
25 |
|
|
3.5 |
kA |
I2t |
I2t for fusing coordination |
|
|
61 |
A2s*103 |
||
Tstg |
Stored temperature |
|
|
-40 |
|
125 |
℃ |
Rth(j-c) |
Thermal resistance Junction to case |
Per Leg , side cooled |
|
|
|
0.15 |
℃ /W |
VFM |
Peak forward voltage |
Per Leg @IFM=200A |
25 |
|
|
1.15 |
V |
|
trr |
Recovery Time |
IFM=200A, VR=200V, di/dt=-100A/ μs |
25 |
|
45 |
50 |
ns |
100 |
|
120 |
|
ns |
|||
|
Fm |
Terminal connection torque(M6) |
|
|
|
6.0 |
|
N·m |
Mounting torque(M6) |
|
|
|
6.0 |
|
N·m |
|
Wt |
Weight |
|
|
|
96 |
|
g |
Outline |
235H3 |
||||||
